SMC SERIES MULTI TURN TRANSMISSION

SMC actuators can be controlled individually or collectively. It can be operated locally or via a remote controller. In addition to the basic models, there are other models such as Explosion-proof (Explosion-proof Grade dllBT4), Integral, Integral Explosion-proof, Radiation-proof, Auto-Regulation, Two-Wire, Two-Speed Control, etc. Various actuators of different protection classes such as Water-Resistant, Marine Type, Fire-Proof are available on request. With a wide range of selection, SMC series of actuators are able to meet various requirements.

Categories: Mechanical Service & HVAC, Others

Description

SPECIFICATIONS

Ambient Temperature	-20°C…55°C
Relative Humidity	Max. 90%
Sea Level Height	Max.1000m
Working Conditions	Without flammable, explosive, corrossive medium
Protection Class	IP65(IP68 for Submarine Type, To Specify When Order)
Power Supply	380V, 50Hz

PERFORMANCE

Model	Output Torque (N*m)	Thrust Allowed (kN)	Max. Stem Diameter (mm)	Output Speed (r/min)	Motor (kw)
SMC-04	110	35	24	20 35	0.2 0.3
SMC-03	270	45	36	18 27	0.4 0.6
SMC-00	500	90	50	24 42	1.1 1.5
SMC-0	970	150	65	18 31	1.5 2.2
SMC-1	1800	250	76	12 18	2.2 3
SMC-2	2700	300	89	10 18	3 4
