F83DJ DOUBLE SPHERE RUBBER FLEXIBLE JOINT

Fig No.: F83DJ16 (PN16) / F83DJ25 (PN25)

GENERAL

  • Absorbs and reduces vibration and shock in the system.
  • Absorbs the stress generated by the expansion and compression of the pipe line.
  • Provides flexibility to the system as allowance connection and installation error.
  • Excellent resistance against pressure.
  • Control rods available upon request.

FEATURES

  • Molded and vulcanized in hydraulic presses.
  • Solid carbon steel internal reinforcing ring.
  • With BS 4504 PN16 / EN 1092-2 PN16 / BS 4504 PN25 / EN 1092-2 PN25 / ANSI Class 150 floating flanges (Specify on order).

APPLICATIONS

  • Building Services, Air-Conditioning, Fire-Protection, Cold Water Plumbing, Sewerage & Water Treatment, Marine Services, General Industries.
  • Suitable for suction and discharge within specify working pressure.
