PRESSURE & TEMPERATURE RATINGS
| Working Pressure | 10bar Water Non-Shock |
| Testing Pressure (x1.5) | 15bar Hydrostatic |
| Working Temperature | -10°C … 70°C |
| Suitable Media | Water |
MATERIAL SPECIFICATIONS
| Part | Material | Specification |
|---|---|---|
| Body | Brass | EN 12165 CW617N |
| Disc | Brass | EN 12165 CW617N |
| Stem | Brass | EN 12165 CW617N |
| Cap | Brass | EN 12165 CW617N |
| Gasket | NBR | |
| Air Cap | Brass | EN 12165 CW617N |
| Connector | Brass | EN 12165 CW617N |
| Core | Brass | EN 12165 CW617N |
DIMENSIONS
| DN | (mm)
(inch) |
15
1/2 |
20
3/4 |
25
1 |
| L | 50 | 50 | 50 | |
| H | 68 | 68 | 68 |
