1353 BS Butterfly Valve Wafer Type

PN20 / 300PSI Fig No.: 1353


  • Valve Standards:
    Complies with EN593/BS5155/MSS SP-67
  • Working Pressure and Temperature:
    Working pressure PN20/300PSI
    Temperature from -10°C to 100°C for EPDM coated disc
    Temperature from -10°c to 82°C for NBR coated disc
  • Top Flange:
    Complies with ISO5211/1
  • End-to-End:
    Dimensions according to MSS SP-67-2002
  • Flange Types:
    BSEN 1092-2 PN16, ANSI B16.1 Class125
  • Operator:
    Gear operator: With two internal CE approved switches
