PN16     Fig No.: F58S16-50 (SS304) / F58S16-51 (SS316)

FEATURES & SPECIFICATIONS
Comply with DIN 11851.
Stainless steel material with excellent corrosion resistance.
Small and lightweight, easy to disassemble and repair.
Easy and flexible installation, can be installed in any position.
End connection comply with ISO 2852 sanitary standard.
Applicable for Building Services, Air-Conditioning, Cold Water Plumbing, Liquid Cooling System, General Industries, etc.
Working pressure : 16bar.
Shell test pressure (x1.5) : 24bar.
Seat test pressure (x1.1) : 17.6bar.
Working temperature : -20°C … 120°C.
Suitable Media : Water.
