Material Specification
| Name | Material |
|---|---|
| Operating Nut | Bronze ASTM B62 |
| Hold Down Nut | Bronze ASTM B62 |
| O-Ring | NBR |
| Bonnet | Ductile lron A536-65-45-12 |
| Bonnet Bolt & Nut | Stainless Steel AISI 201 |
| Upper Rod | Carbon Steel AISI 1045 |
| Pumper Nozzle | Bronze ASTM B62 |
| Pumper Nozzle Gasket | NBR |
| Hose Nozzle | Bronze ASTM B62 |
| Hose Nozzle Gasket | NBR |
| Pumper Nozzle Cap | Ductile Iron A536-65-45-12 |
| Hose Nozzle Cap | Ductile Iron A536-65-45-12 |
| Cap Chain | Carbon Steel Plated |
| Standpipe Upper | Ductile Iron A536-65-45-12 |
| Safety Coupling | Stainless Steel A890 |
| Safety Flange Bolt & Nut | Stainless Steel AISI 201 |
| Safety Flange | Ductile Iron A536-65-45-12 |
| Lower Rod | Carbon Steel AISI 1045 |
| Standpipe Lower | Ductile Iron A536-65-45-12 |
| Stem Pin | Stainless Steel A276 |
| Drain Ring Housing | Ductile Iron A536-65-45-12 |
| Drain Ring | Bronze ASTM B62 |
| Seat Ring | Bronze ASTM B62 |
| Bottom Plate | Ductile Iron A536-65-45-12 |
| Disc Ring | NBR |
| Bottom Plate Nut | Ductile Iron A536-65-45-12 |
| Elbow | Ductile Iron A536-65-45-12 |
BURY DEPTH
| Bury Depths | 3′-0″ | 3′-6″ | 4′-0″ | 4′-6″ | 5′-0″ | 5′-6″ | 6′-0″ |
