PN25 Fig No.: F83H

SPECIFICATIONS

Flange drilled to BS 4504 PN25/ BS EN 1092-2 PN25 / ANSI CLASS
150 (Specify on order)
Stainless Steel 304 internal bellow and external braiding

APPLICATIONS

Designed to compensate for piping misalignment and movement
To accomodate vibration, reduce noise, relief stress and prevent system shock.
Suitable for applications such as pumps, compressors and other mechanical equipment.
Applicable to Building Services, Air-Conditioning, Fire-Protection, Cold Water Plumbing & Sanitary, Hot Water System, General Industries, etc.

分类：机械服务和暖通空调, 管件

描述

PRESSURE & TEMPERATURE RATINGS

Working Pressure	25bar .
Testing Pressure	(x1.5) 37.5bar
Working Temperature	Maximum 220°C
Suitable Media	Water, Air, Steam, Oil, Gas

Material Specification

Part	Material
Ring	Carbon Steel
Bellow	Stainless Steel 304
Braiding	Stainless Steel 304
Flange	Carbon Steel Stainless Steel 304

DIMENSIONS & MOVEMENTS

DN

(mm)

(inch)

20

³/4

25

1

32

1¹/4

40

1¹/2

50

2

65

2¹/₂

80

3

100

4

125

5

150

6

200

8

250

10

300

12

L

300

300

300

300

300

300

300

300

300

300

300

300

300

Lateral Movement

30

30

30

30

30

30

30

25

20

20

10

5

5

Special length available on request.
