SPECIFICATIONS
| Casing Length | 9” (228mm) |
| Stem Length | 3.5” (89mm) |
| 6″ (150mm) | |
| Casing | Black V-shaped aluminium |
| Lens | Glass, Magnifying lens tube |
| Stem Material | Brass |
| Stainless Steel 304 | |
| Stainless Steel 316 | |
| Thermowell Connection | 3/4” NPT |
| Connection | Swivel nut with 11/4” – 18 NEP Thread |
| Scale Reading | Celsius (°C) & Fahrenheit (°F) |
| Ambient Temperature | -30°C … 100°C |
PRODUCT IDENTIFICATION CODE
| FT31 | – | 228 | x | 150 | . | 0/120 | ||
| Model / Stem Material | Adjustable Angle / Brass | FT31 | ||||||
| Adjustable Angle / SUS 304 | FT32 | |||||||
| Adjustable Angle / SUS 316 | FT33 | |||||||
| Casing Length | 9″ (228mm) | 228 | ||||||
| Stem Length | 3.5″ (89mm) | 089 | ||||||
| 6″ (150mm) | 150 | |||||||
| Temperature Range | 0 … 120°C ; 30 … 250°F | 0/120 | ||||||
| -0 … 140°C ; 30 … 300°F | 0/140 | |||||||
| -10 … 80°C ; 20 … 180°F | 010/80 | |||||||
| -20 … 15°C ; 0 … 60°F | 020/15 | |||||||
| -20 … 50°C ; 0 … 120°F | 020/50 | |||||||
| -40 … 40°C ; -40 … 110°F | 040/40 |
