PRESSURE & TEMPERATURE RATINGS
| Working Pressure | 20bar WOG Non-Shock
10bar Saturated Steam |
| Shell Testing Pressure | (x1.5) 30bar Hydrostatic |
| Working Temperature | -10°C … 170°C |
| Suitable Media | Water, Oil & Gas |
MATERIAL SPECIFICATIONS
| Part | Material | Specification |
|---|---|---|
| Body | Bronze | EN 1982 GC490K |
| Cap | Bronze | EN 1982 GC490K |
| Screen | Stainless Steel 304 | EN 1449 304S31 |
| Gasket | PTFE |
DIMENSIONS
| DN | (mm)
(inch) |
15
1/2 |
20
3/4 |
25
1 |
32
1 1/4 |
40
1 1/2 |
50
2 |
| L | 58.5 | 70.5 | 88 | 96.5 | 107 | 126 | |
| H | 41 | 50 | 59 | 69 | 76 | 96 |
